Aluminium Shop-front Doors & Automatic Sliding Entrances Supply & Installation — 1 automatic entrance + 1 double door + 1 single door · per attached Shop Drawing SD-01

Client

—

Units

1 C · 1 B · 1 A

Glass Area

21.50 m²

Glass

10 mm tempered

#	Description of Works & Specifications	Size (cm)	Qty	Area (m²)
1	Front automatic sliding entrance (Type C). 2 motorised sliding leaves + 2 fixed panels (1080 mm each, 2000 mm clear opening) flanked by 2 × 90 cm swing doors that open normally. Header beam 200×165×3.5 mm housing the operator, side frames 60×165×2.0 mm, leaves 80×44×2.0 mm, rails 90×44×2.0 mm and floor guides. Glazed with 10 mm clear tempered glass.	620 × 250	1	15.50
2	Double swing door, back of building (Type B, 2 × 70 cm leaves). Aluminium frame 50×100×1.4 mm, leaf 50×44×2.0 mm, top/bottom rails 90×44×2.0 mm. Glazed with 10 mm clear tempered glass.	150 × 240	1	3.60
3	Single swing door, back of building (Type A). Same profile system. Glazed with 10 mm clear tempered glass.	100 × 240	1	2.40
4	Automatic sliding operator — RECORD (Switzerland). Complete motor drive unit, controller, photocell / motion & presence sensors and key switch for the two sliding leaves, installed and commissioned.	—	1	—
5	Door accessories (per door). Floor spring / pivots, long pull handle and lock for each normal swing door: 2 side doors of the front entrance + 1 double door + 1 single door.	—	4	—
TOTAL GLASS AREA				21.50

TOTAL PRICE — supply & installation, all items 1–5

EGP —

Notes & Terms

• The total price is a lump sum covering all items above: aluminium, glass, the RECORD (Switzerland) automatic operator with sensors, door accessories, supply and installation.
• Glass: 10 mm clear tempered safety glass to EN 12150 — 9 panels (see cutting list in SD-01).
• Profile sizes are taken from the client's drawing. Aluminium colour/finish to be confirmed by the client.
• Payment terms: 70% advance on contract, 30% on installation.
• Dimensions are to be re-measured on site before fabrication and execution.
• This quotation is valid for 15 days from its date.

For / BlueCrest Glass & Facades

Submitted by — Signature & Stamp

For / Client

Approved — Signature & Stamp

BlueCrest Trading S.A.E — Cairo, Egypt bluecresttr.com • sales@bluecresttr.com • +20 100 013 3391

SHOP DRAWING

Aluminium Shop-front Doors + Automatic Sliding Entrances

Client: — • Ref: BC-QTN-2026-027 • Drawing SD-01

A. 3D MODEL — Front entrance (C) · Back doors (A · B)

SENSOR: idle

3D view of the shop-front doors and automatic sliding entrance

drag to rotate • scroll/pinch to zoom • double-tap to auto-spin

Glass Specification

10 mm clear temperedMonolithic safety glass · EN 12150 · polished edges

Glass thickness is not stated on the client drawing — to be confirmed against the leaf glazing pocket (44 mm leaf depth).

Panels9 pcs

Net glass16.21 m²

Edge length54.88 m.l.

Weight ≈405 kg

Aluminium Profiles (from client drawing)

Member	Types A · B (shop-front)	Type C (automatic)
Header beam	—	200×165×3.5
Outer frame	50×100×1.4	60×165×2.0
Leaf stile	50×44×2.0	80×44×2.0
Top/bottom rail	90×44×2.0	90×44×2.0

Face width × depth × wall thickness, mm.

Unit Summary — 3 openings

Type	Size (mm)	Qty	Priced m²	Net glass
A single swing	1000 × 2400	1	2.40	1.70
B double swing	1500 × 2400	1	3.60	2.54
C automatic	6200 × 2500	1	15.50	11.97
TOTAL (m²)		3	21.50	16.21

Type C: 2 × 900 swing doors + 2 fixed + 2 sliding leaves (1080 each), doors 2500 high under a 200 beam — 2000 mm clear opening, operator & sensor in the 200 mm header beam.

BlueCrest Trading S.A.E — Architectural Glass & Facades SD-01 · Sheet 1 of 3

B. TYPE A — ELEVATION (×1)

NTS · mm

C. TYPE B — ELEVATION (×1)

NTS · mm

D. TYPE C — AUTOMATIC ENTRANCE ELEVATION (×1)

NTS · mm

E. TYPE C — PLAN (open position shown dashed)

NTS · mm

F. LEGEND

Clear tempered glass

Aluminium frame / leaf profile

Swing leaf — apex points to hinge side

Motorised sliding leaf (direction)

Fixed glazed panel

Glass cut size in mm (width × height) — e.g. 920×2320

G. TYPES A & B — BACK DOORS

Narrow-stile aluminium swing doors on floor springs (double-action) with full-height glass and a long vertical pull handle on each leaf.
Frame 50×100×1.4 · leaf 50×44×2.0 · rails 90×44×2.0.
Type A: 1 leaf 900 wide · Type B: 2 leaves 700 wide each.

H. TYPE C — AUTOMATION

RECORD (Switzerland) operator (motor, belt drive, controller) concealed in the 200×165 header beam.
Microwave motion sensor + safety presence beams on both faces open the two centre leaves to a 2000 mm clear opening and close them after a set hold-open time.
Side 900 swing doors serve as manual / emergency exits.

J. SITE NOTES

• All sizes are overall frame sizes in mm, taken from the client drawing.
• Glass sizes are net estimates — final cut sizes after profile shop-detailing.
• Re-measure every opening on site before fabrication.
• Aluminium finish and glass thickness to be confirmed.

BlueCrest Trading S.A.E — Architectural Glass & Facades SD-01 · Sheet 2 of 3

Glass Cutting List — 9 pcs · 10 mm clear tempered

#	Type	Position	Glass W × H (mm)	Pcs / unit	Units	Total pcs	Area each (m²)	Area total (m²)	Edge (m.l.)
1	A single swing	Door leaf	800 × 2120	1	1	1	1.696	1.70	5.84
2	B double swing	Door leaves (L + R)	600 × 2120	2	1	2	1.272	2.54	10.88
3	C automatic	Side swing doors (L + R)	740 × 2320	2	1	2	1.717	3.43	12.24
4	C automatic	Fixed side panels (L + R)	920 × 2320	2	1	2	2.134	4.27	12.96
5	C automatic	Motorised sliding leaves (L + R)	920 × 2320	2	1	2	2.134	4.27	12.96
TOTAL GLASS						9		16.21	54.88

Net glass = leaf size − 2 × stile − 2 × rail (A/B: stile 50, rail 90, 50 frame all round · C: stile 80, rail 90, leaves full 2500 height). Glazing bite not included.

Priced Areas

Type	W × H (mm)	m² / unit	Units	Total m²
A — single swing door	1000 × 2400	2.40	1	2.40
B — double swing door	1500 × 2400	3.60	1	3.60
C — automatic entrance (glazed 2500, beam excluded)	6200 × 2500	15.50	1	15.50
TOTAL			3	21.50

Hardware per unit

Type	Hardware
A	1 floor spring + top pivot · 1 long pull handle (≈1700) · lock
B	2 floor springs + top pivots · 2 long pull handles · lock + flush bolt
C	Automatic sliding operator (2-leaf) · 2 motion/presence sensors · controller & key switch · floor guides · 2 floor springs · 2 pull handles (1990)

Notes & Specifications

• Scope: 1 front automatic sliding entrance (Type C) + 1 double swing door (Type B) and 1 single swing door (Type A) at the back of the building.
• Glass: 10 mm clear tempered safety glass to EN 12150, polished edges — 9 panels / 16.21 m² net. Thickness to be confirmed against the 44 mm leaf glazing pocket.
• Type C: header beam 200×165×3.5 houses the operator; two centre leaves slide apart to a 2000 mm clear opening on sensor signal; fixed side panels behind; 900 swing doors each side.
• All dimensions in mm, overall frame sizes. Re-measure on site before fabrication; glass cut sizes are final only after shop detailing.
• Aluminium colour / finish to be confirmed by the client (shown dark grey).

BlueCrest Glass & FacadesCairo, Egypt

Project

Shop-front & Auto Doors

Client

—

Drawing No.

SD-01

Reference

BC-QTN-2026-027

Date

17 / 10 / 2026
